1.缸体带有外环螺纹，柱塞有内螺纹，底部有安装孔，使其应用广泛。
2.缸体顶部及柱塞底部均带有合金导向套，可吸收偏载力及延长液压缸的使用寿命。
3.缸体顶部配有防尘圈。
4.内置弹簧，自动回缩，使用更方便。
|
型号 |
承载能力@700bar Ton kN |
行程 mm |
有效面积cm2 |
液压油 容量 cm3 |
本体高度 A mm |
伸展高度 B mm |
外径 D mm |
柱塞直径F mm |
重量kg |
|
|
SS00501 |
5 |
45 |
16 |
8 |
13 |
67 |
81 |
45 |
26 |
1.1 |
|
SS00502 |
5 |
45 |
25 |
8 |
20 |
132 |
157 |
45 |
26 |
1.2 |
|
SS00508 |
5 |
45 |
76 |
8 |
61 |
181 |
257 |
45 |
26 |
1.7 |
|
SS00513 |
5 |
45 |
127 |
8 |
102 |
232 |
359 |
45 |
26 |
2.2 |
|
SS00518 |
5 |
45 |
177 |
8 |
142 |
290 |
466 |
45 |
26 |
2.7 |
|
SS00523 |
5 |
45 |
232 |
8 |
186 |
342 |
574 |
45 |
26 |
3.2 |
|
SS01003 |
10 |
99 |
26 |
15.9 |
41.3 |
94 |
120 |
60 |
38 |
1.9 |
|
SS01005 |
10 |
99 |
54 |
15.9 |
85.9 |
123 |
177 |
60 |
38 |
2.4 |
|
SS01010 |
10 |
99 |
105 |
15.9 |
167 |
176 |
281 |
60 |
38 |
3.4 |
|
SS01016 |
10 |
99 |
156 |
15.9 |
248 |
273 |
429 |
60 |
38 |
4.7 |
|
SS01020 |
10 |
99 |
203 |
15.9 |
322.8 |
322 |
525 |
60 |
38 |
5.7 |
|
SS01026 |
10 |
99 |
257 |
15.9 |
408.6 |
375 |
632 |
60 |
38 |
6.7 |
|
SS01030 |
10 |
99 |
304 |
15.9 |
483.4 |
426 |
730 |
60 |
38 |
7.1 |
|
SS01036 |
10 |
99 |
356 |
15.9 |
566 |
478 |
834 |
60 |
38 |
8.5 |
|
SS01502 |
15 |
139 |
25 |
21.2 |
53 |
140 |
165 |
70 |
40 |
3.5 |
|
SS01505 |
15 |
139 |
51 |
21.2 |
108.1 |
165 |
216 |
70 |
40 |
4.4 |
|
SS01510 |
15 |
139 |
101 |
21.2 |
214.1 |
217 |
318 |
70 |
40 |
5.3 |
|
SS01515 |
15 |
139 |
152 |
21.2 |
322.2 |
271 |
423 |
70 |
40 |
7.1 |
|
SS01520 |
15 |
139 |
203 |
21.2 |
430.4 |
338 |
541 |
70 |
40 |
8.6 |
|
SS01525 |
15 |
139 |
254 |
21.2 |
538.5 |
389 |
643 |
70 |
40 |
10 |
|
SS01530 |
15 |
139 |
305 |
21.2 |
646.6 |
440 |
745 |
70 |
40 |
11.3 |
|
SS01536 |
15 |
139 |
356 |
21.2 |
754.7 |
489 |
845 |
70 |
40 |
12.2 |
|
SS02502 |
25 |
228 |
26 |
33.2 |
86.3 |
169 |
195 |
86 |
56 |
6.7 |
|
SS02505 |
25 |
228 |
50 |
33.2 |
166 |
194 |
244 |
86 |
56 |
7.2 |
|
SS02510 |
25 |
228 |
102 |
33.2 |
338.6 |
246 |
348 |
86 |
56 |
9 |
|
SS02516 |
25 |
228 |
158 |
33.2 |
524.6 |
301 |
459 |
86 |
56 |
10.8 |
|
SS02520 |
25 |
228 |
210 |
33.2 |
697.2 |
350 |
560 |
86 |
56 |
13 |
|
SS02526 |
25 |
228 |
261 |
33.2 |
866.5 |
401 |
662 |
86 |
56 |
15 |
|
SS02531 |
25 |
228 |
311 |
33.2 |
1032.5 |
451 |
762 |
86 |
56 |
17.1 |
|
SS02536 |
25 |
228 |
362 |
33.2 |
1202 |
502 |
864 |
86 |
56 |
18.5 |
|
SS05005 |
50 |
488 |
51 |
71 |
362.1 |
176 |
227 |
127 |
80 |
15.1 |
|
SS05010 |
50 |
488 |
101 |
71 |
717.1 |
227 |
328 |
127 |
80 |
19.2 |
|
SS05016 |
50 |
488 |
159 |
71 |
1129 |
283 |
442 |
127 |
80 |
23.3 |
|
SS05034 |
50 |
488 |
337 |
71 |
2393 |
466 |
803 |
127 |
80 |
37.8 |
