◆完全符合美国ASME B30.1安全标准,高强度全金钢材料保证有2倍安全系数
◆适用于大吨位的顶升场合.
◆双作用,液压回位.
◆镀铬活塞杆抗腐蚀及耐磨损.
◆标准的安装孔设于底部.
◆缸内表面特殊工艺处理保证更耐久的使用.
◆NPTF干密封螺纹设计并配备有高性能快速接头.
◆经特殊处理的烤漆表面提供更强腐蚀能力.
|
承载能力@700barton(kN) |
行程(mm) |
型号 |
有效面积(cm2) |
液压油容量(cm3) |
本体高度A(mm) |
||
|
推 |
拉 |
推 |
拉 |
||||
| 50(539) | 50 | EDX-502 | 77.0 | 38.5 | 385 | 192 | 162 |
| 100 | EDX-504 | 77.0 | 38.5 | 770 | 385 | 212 | |
| 150 | EDX-506 | 77.0 | 38.5 | 1155 | 577 | 262 | |
| 200 | EDX-508 | 77.0 | 38.5 | 1540 | 770 | 312 | |
| 250 | EDX-5010 | 77.0 | 38.5 | 1924 | 962 | 362 | |
| 300 | EDX-5012 | 77.0 | 38.5 | 2309 | 1155 | 412 | |
| 100(929) | 50 | EDX-1002 | 132.7 | 61.9 | 664 | 309 | 182 |
| 100 | EDX-1004 | 132.7 | 61.9 | 1327 | 619 | 232 | |
| 150 | EDX-1006 | 132.7 | 61.9 | 1991 | 928 | 282 | |
| 200 | EDX-1008 | 132.7 | 61.9 | 2655 | 1237 | 332 | |
| 250 | EDX-10010 | 132.7 | 61.9 | 3318 | 1546 | 382 | |
| 300 | EDX-10012 | 132.7 | 61.9 | 3982 | 1856 | 432 | |
| 150(1390) | 50 | EDX-1502 | 198.6 | 96.5 | 993 | 482 | 196 |
| 100 | EDX-1504 | 198.6 | 96.5 | 1986 | 965 | 246 | |
| 150 | EDX-1506 | 198.6 | 96.5 | 2978 | 1447 | 296 | |
| 200 | EDX-1508 | 198.6 | 96.5 | 3971 | 1930 | 346 | |
| 250 | EDX-15010 | 198.6 | 96.5 | 4964 | 2412 | 396 | |
| 300 | EDX-15012 | 198.6 | 96.5 | 5957 | 2895 | 446 | |
| 200(1861) | 50 | EDX-2002 | 265.9 | 127.0 | 1330 | 635 | 216 |
| 150 | EDX-2006 | 265.9 | 127.0 | 3989 | 1905 | 316 | |
| 300 | EDX-20012 | 265.9 | 127.0 | 7977 | 3809 | 466 | |
| 250(2565) | 50 | EDX-2502 | 366.4 | 152.6 | 1832 | 763 | 235 |
| 150 | EDX-2506 | 366.4 | 152.6 | 5497 | 2289 | 335 | |
| 300 | EDX-25012 | 366.4 | 152.6 | 10993 | 4578 | 485 | |
| 300(3193) | 50 | EDX-3002 | 456.2 | 151.4 | 2281 | 757 | 312 |
| 150 | EDX-3006 | 456.2 | 151.4 | 6843 | 2270 | 412 | |
| 300 | EDX-30012 | 456.2 | 151.4 | 13685 | 4541 | 562 | |
| 400(3919) | 50 | EDX-4002 | 559.9 | 193.5 | 2800 | 967 | 375 |
| 150 | EDX-4006 | 559.9 | 193.5 | 8399 | 2902 | 475 | |
| 300 | EDX-40012 | 559.9 | 193.5 | 16797 | 5804 | 625 | |
| 500(5114) | 50 | EDX-5002 | 730.6 | 247.6 | 3653 | 1238 | 419 |
| 150 | EDX-5006 | 730.6 | 247.6 | 10959 | 3713 | 519 | |
| 300 | EDX-50012 | 730.6 | 247.6 | 21918 | 7427 | 669 | |
| 600(5987) | 50 | EDX-6002 | 855.3 | 295.4 | 4276 | 1477 | 429 |
| 150 | EDX-6006 | 855.3 | 295.4 | 12829 | 4431 | 529 | |
| 300 | EDX-60012 | 855.3 | 295.4 | 25659 | 8862 | 679 | |
| 800(8234) | 50 | EDX-8002 | 1176.3 | 387.0 | 5881 | 1935 | 474 |
| 150 | EDX-8006 | 1176.3 | 387.0 | 17644 | 5806 | 574 | |
| 300 | EDX-80012 | 1176.3 | 387.0 | 35288 | 11611 | 72 | |
| 1000(10260) | 50 | EDX-10002 | 1465.7 | 541.7 | 7329 | 2709 | 564 |
| 150 | EDX-10006 | 1465.7 | 541.7 | 21986 | 8126 | 664 | |
| 300 | EDX-100012 | 1465.7 | 541.7 | 43972 | 16252 | 814 | |
