三通保温旋塞阀基本尺寸 |
|
口径(DN) |
L |
D |
D1 |
D2 |
z-Φd |
|
20 |
150 |
105 |
75 |
55 |
4-Φ14 |
|
25 |
160 |
115 |
85 |
65 |
4-Φ14 |
|
32 |
190 |
135 |
100 |
78 |
4-Φ18 |
|
40 |
200 |
145 |
110 |
85 |
4-Φ18 |
|
50 |
220 |
160 |
125 |
100 |
4-Φ18 |
|
65 |
280 |
180 |
145 |
120 |
4-Φ18 |
|
80 |
300 |
195 |
160 |
135 |
4-Φl8 |
|
100 |
340 |
215 |
180 |
155 |
8-Φ18 |
|
125 |
350 |
245 |
210 |
185 |
8-Φ18 |
|
150 |
400 |
280 |
240 |
210 |
8-Φ18 |
|
200 |
450 |
335 |
295 |
265 |
8-Φ23 |
